Ropeway Database - 15-GUB Furgg-Schwarzsee (Zermatt)
15-GUB Furgg-Schwarzsee
Photo provided by: Felix
Technical data
| Bottom station altitude | 2439 | m |
| Top station altitude | 2586 | m |
| Difference in altitude | 147 | m |
| Length | 419 | m |
| Capacity | 1750 | P/h |
| Travel time | 3 | min |
| Speed | 5 | m/s |
| Number of towers | 4 | |
| Number of carriers | 10 | |
| Drive terminal | Bottom station | |
| Tensioning terminal | Top station | |
| Carrier manufacturer | CWA | |
| Rope manufacturer | ||
| Electronics manufacturer | ||
| Transportation uphill | Yes | |
| Transportation downhill | Yes | |
| Remarks | None | |
Chronicle
The installation replaces the following ropeway(s)
The installation was previously located in the following place
-
-
15-GUB Furgg-Schwarzsee
After dismantling, the installation was set up again at the following location
-
-
The installation was replaced by the following ropeway(s)
Photos of this ropeway
Videos of this ropeway
Currently, there are no videos of this ropeway available.
Location of the installation
Coordinates (decimal): Bottom station 45.9881 N / 7.71336 E, Top station 45.99041 N / 7.70989 E
Location of the installation: Google Maps • Swisstopo • Swisstopo (historisch)
