Surface lift Stafel in Blatten
2-person Surface lift Stafel
AI Abstract
With a length of 210 meters, the Stafel cable car in Blatten (Valais) connects stations at elevations of 2020 m and 2036 m. The cable car was built in 1989 by Von Roll. The maximum capacity is 1000 people per hour.
| Country |
|
|---|---|
| Canton / State |
|
| Location | Blatten (Belalp) |
| Name | Stafel |
| Type | 2-SLE (SUMF-E2) |
| Operating Time | 1989 - To date |
| Manufacturer | Von Roll |
| Status |
 |
- Country: Switzerland
- Canton / State: Valais
- Location: Blatten (Belalp)
- Name: Stafel
- Type: 2-SLE
- Operating Time: 1989-To date
- Year of construction: 1989
- Manufacturer: Von Roll
- Status: In operation
- Bottom station altitude: 2020 m
- Difference in altitude: 16 m
- Length: 210 m
- Capacity: 1000 P/h
- Travel time: 1 min
- Speed: 3,2 m/s
- Number of towers: 2
- Drive terminal: Top station
- Tensioning terminal: Bottom station
- Carrier manufacturer: Von Roll
- Rope manufacturer: Fatzer
- Electronics manufacturer: Gfeller
- Transportation uphill: Yes
- Transportation downhill: No
Frequently asked questions
What is the ropeway Stafel?
The Stafel ropeway is a 2-person Surface lift in Blatten and connects the valley station at 2020 m to the mountain station at 2036 m.
What is the hourly passenger capacity of the Stafel ropeway?
The maximum capacity of the Stafel ropeway is 1000 people per hour.
When was the Stafel ropeway constructed?
The Stafel ropeway was constructed in 1989.
Where is the Stafel ropeway located?
The Stafel ropeway is operating in Blatten (Switzerland).
How long is the Stafel ropeway?
The diagonal length of the Stafel ropeway is 210 meters.
What is the elevation gain of the Stafel ropeway?
The Stafel ropeway covers an elevation gain of 16 meters.
Who is the manufacturer of the Stafel ropeway?
The Stafel ropeway was constructed by the company Von Roll.
Technical data
| Bottom station altitude | 2020 | m |
|---|---|---|
| Top station altitude | 2036 | m |
| Difference in altitude | 16 | m |
| Length | 210 | m |
| Capacity | 1000 | P/h |
| Travel time | 1 | min |
| Speed | 3,2 | m/s |
| Number of towers | 2 | |
| Number of carriers | ||
| Drive terminal | Top station | |
| Tensioning terminal | Bottom station | |
| Carrier manufacturer | Von Roll | |
| Rope manufacturer | Fatzer | |
| Electronics manufacturer | Gfeller | |
| Transportation uphill | Yes | |
| Transportation downhill | No | |
| Remarks | None | |
Chronicle
-
-
-
-
Photos of this ropeway
Videos of this ropeway
Location of the installation
Coordinates (decimal): Bottom station 46.36821 N / 7.96525 E, Top station 46.36977 N / 7.9669 E
Location of the installation: Google Maps • Swisstopo
