Ropeway Database - 80-LPB Parsennhütte-Weissfluhjoch (Davos)
80-LPB Parsennhütte-Weissfluhjoch
Last update: 10.12.2017 12:43 (Updated by swisstrains)
Photo provided by: Felix
Technical data
| Bottom station altitude | 2212 | m |
| Top station altitude | 2677 | m |
| Difference in altitude | 465 | m |
| Length | 2379 | m |
| Capacity | 675 | P/h |
| Travel time | 5 | min |
| Speed | 9 | m/s |
| Number of towers | 4 | |
| Number of carriers | 2 | |
| Drive terminal | Top station | |
| Tensioning terminal | Bottom station | |
| Carrier manufacturer | CWA | |
| Rope manufacturer | Fatzer | |
| Electronics manufacturer | Frey | |
| Transportation uphill | Yes | |
| Transportation downhill | Yes | |
| Remarks | Schiebeperrons in den Stationen. Viele Teile der Vorgängerbahn übernommen. Kabinen stammen von der alten Gotschnabahn. | |
Chronicle
The installation replaces the following ropeway(s)
The installation was previously located in the following place
-
-
80-LPB Parsennhütte-Weissfluhjoch
After dismantling, the installation was set up again at the following location
-
-
The installation was replaced by the following ropeway(s)
-
-
Photos of this ropeway
Videos of this ropeway
Please enable marketing cookies to view this content.
Location of the installation
Coordinates (decimal): Bottom station 46.85057 N / 9.82509 E, Top station 46.83395 N / 9.80646 E
Location of the installation: Google Maps • Swisstopo
Please enable marketing cookies to view this content.
Map legend:
Ropeway in operation
Ropeway out of operation
Ropeway dismantled
