Ropeway Database - 100-LPB Arosa-Mittlere Hütte (Arosa)
100-LPB Arosa-Mittlere Hütte
Photo provided by: Felix
Technical data
| Bottom station altitude | 1752 | m |
| Top station altitude | 2013 | m |
| Difference in altitude | 261 | m |
| Length | 1237 | m |
| Capacity | 1200 | P/h |
| Travel time | 5 | min |
| Speed | 9 | m/s |
| Number of towers | 4 | |
| Number of carriers | 2 | |
| Drive terminal | Top station | |
| Tensioning terminal | Bottom station | |
| Carrier manufacturer | Gangloff | |
| Rope manufacturer | Fatzer | |
| Electronics manufacturer | Frey | |
| Transportation uphill | Yes | |
| Transportation downhill | Yes | |
| Remarks | None | |
Chronicle
The installation replaces the following ropeway(s)
The installation was previously located in the following place
-
-
100-LPB Arosa-Mittlere Hütte
After dismantling, the installation was set up again at the following location
-
-
The installation was replaced by the following ropeway(s)
-
-
Photos of this ropeway
Videos of this ropeway
Please enable marketing cookies to view this content.
Location of the installation
Coordinates (decimal): Bottom station 46.78358 N / 9.6786 E, Top station 46.78631 N / 9.66331 E
Location of the installation: Google Maps • Swisstopo
