Gondola Sogn Martin-La Siala in Flims
10-person Gondola Sogn Martin-La Siala
AI Abstract
The Sogn Martin-La Siala cable car in Flims (built in 2015) spans a distance of 3366 meters, covering an elevation difference between 1977 m and 2809 m. It was built by Leitner. The maximum capacity is 2000 people per hour.
| Country |
|
|---|---|
| Canton / State |
|
| Location | Flims (Flims-Laax-Falera) |
| Name | Sogn Martin-La Siala |
| Type | 10-KBK (LUMK-K10) |
| Operating Time | 2015 - To date |
| Manufacturer | Leitner |
| Status |
|
- Country: Switzerland
- Canton / State: Grisons
- Location: Flims (Flims-Laax-Falera)
- Name: Sogn Martin-La Siala
- Type: 10-KBK
- Operating Time: 2015-To date
- Year of construction: 2015
- Manufacturer: Leitner
- Status: In operation
- Bottom station altitude: 1977 m
- Difference in altitude: 832 m
- Length: 3366 m
- Capacity: 2000 P/h
- Travel time: 9,35 min
- Speed: 6 m/s
- Number of towers: 18
- Number of carriers: 70
- Drive terminal: Top station
- Tensioning terminal: Bottom station
- Carrier manufacturer: Sigma
- Rope manufacturer: Redaelli
- Electronics manufacturer: Sisag
- Transportation uphill: Yes
- Transportation downhill: Yes
- Remarks: Ausbau auf 84 Kabinen und 2400 P/h möglich.
Frequently asked questions
What is the ropeway Sogn Martin-La Siala?
The Sogn Martin-La Siala ropeway is a 10-person Gondola in Flims and connects the valley station at 1977 m to the mountain station at 2809 m.
What is the hourly passenger capacity of the Sogn Martin-La Siala ropeway?
The maximum capacity of the Sogn Martin-La Siala ropeway is 2000 people per hour.
When was the Sogn Martin-La Siala ropeway constructed?
The Sogn Martin-La Siala ropeway was constructed in 2015.
Where is the Sogn Martin-La Siala ropeway located?
The Sogn Martin-La Siala ropeway is operating in Flims (Switzerland).
How long is the Sogn Martin-La Siala ropeway?
The diagonal length of the Sogn Martin-La Siala ropeway is 3366 meters.
What is the elevation gain of the Sogn Martin-La Siala ropeway?
The Sogn Martin-La Siala ropeway covers an elevation gain of 832 meters.
Who is the manufacturer of the Sogn Martin-La Siala ropeway?
The Sogn Martin-La Siala ropeway was constructed by the company Leitner.
Technical data
| Bottom station altitude | 1977 | m |
|---|---|---|
| Top station altitude | 2809 | m |
| Difference in altitude | 832 | m |
| Length | 3366 | m |
| Capacity | 2000 | P/h |
| Travel time | 9,35 | min |
| Speed | 6 | m/s |
| Number of towers | 18 | |
| Number of carriers | 70 | |
| Drive terminal | Top station | |
| Tensioning terminal | Bottom station | |
| Carrier manufacturer | Sigma | |
| Rope manufacturer | Redaelli | |
| Electronics manufacturer | Sisag | |
| Transportation uphill | Yes | |
| Transportation downhill | Yes | |
| Remarks | Ausbau auf 84 Kabinen und 2400 P/h möglich. | |
Chronicle
-
-
-
Photos of this ropeway
Videos of this ropeway
Location of the installation
Coordinates (decimal): Bottom station 46.85256 N / 9.21402 E, Top station 46.88083 N / 9.20426 E
Location of the installation: Google Maps • Swisstopo
Map legend:
Ropeway in operation
Ropeway out of operation
Ropeway dismantled
